主要技術參數
功率：0.5～30VA
防護等級:IP00 ?????
初級:?110/230V 50/60Hz
次級: 24/48VAC ????????
絕緣等級:Class A、Class B
絕緣強度:3.75KV Rms
環境溫度: (t)-40℃?????????
符合標準:?
EN60065:2006/UL5085-2/UL1446
原理圖：
結構圖：
參考尺寸：
|
功率/VA |
A |
B |
C |
D |
E |
F |
重量/kg |
|
1.5VA |
28.5 |
20.0 |
27.0 |
2P×14.6 |
5P×3.65 |
20.5 |
0.06 |
|
2.5VA |
28.5 |
20.0 |
33.6 |
3P×7.6 |
4P×3.6 |
19.2 |
0.09 |
|
2.0VA |
35.5 |
30.0 |
30.5 |
3P×7.4 |
4P×5.0 |
20.5 |
0.10 |
|
2.5VA |
35.5 |
30 |
36.0 |
5P×4.8 |
5P×4.8 |
21.0 |
0.13 |
|
3.5VA |
35.5 |
30.5 |
38.0 |
2P×19.6 |
5P×4.9 |
21.7 |
0.16 |
|
4.5VA |
41.5 |
33.5 |
32.0 |
2P×26.5 |
7P×4.4 |
25.8 |
0.17 |
|
4.5VA |
41.5 |
33.5 |
40.0 |
4P×7.7 |
5P×5.8 |
23.2 |
0.19 |
|
5.0VA |
41.5 |
33.5 |
38.0 |
2P×26.5 |
7P×4.4 |
25.8 |
0.21 |
|
5.5VA |
41.5 |
33.5 |
43.0 |
4P×7.4 |
8P×5.0 |
23.5 |
0.23 |
|
5.0VA |
48.5 |
33.5 |
20.0 |
7P×5.0 |
7P×5.0 |
25.8 |
0.19 |
|
7.0VA |
48.5 |
40.5 |
37.0 |
5P×7.4 |
5P×7.4 |
29.5 |
0.24 |
|
9.0VA |
48.5 |
40.5 |
41.5 |
5P×7.4 |
6P×5.0 |
29.5 |
0.31 |
|
10.0VA |
48.5 |
40.5 |
43.0 |
5P×7.5 |
5P×7.5 |
29.5 |
0.34 |
|
14.0VA |
48.5 |
40.5 |
46.0 |
5P×7.4 |
5P×7.4 |
29.5 |
0.43 |
|
20.0VA |
57.5 |
50.5 |
51.0 |
7P×5.0 |
7P×5.0 |
32.0 |
0.65 |
|
20.0VA |
66.5 |
55.5 |
48.0 |
9P×5.0 |
9P×5.0 |
38.5 |
0.69 |
接受客戶定做
